MUSICIAN PEGASUS II
R2R DAC
Pegasus has its own upscaling function in the internal, which supports up to 16 times.
Technical Paramerters
Frequency Response: 10Hz~60KHz
THD+N: 0.002%
S/N Ratio: 123dB(A-weighted)
Dynamic Range: >120dB
AC Power Requirement: 110-240VAC, 50/60Hz (Worldwide Voltage)
Power Consumption: ≤20W
Dimension: 280 x 250x 50 mm
Package Dim: 375 x 330 x 115 mm
Package Content: DAC + AC power cable, No remote control.
Weight:3.9 Kg
Color: Silver / Black
Proprietary R2R + DSD Architecture
True balanced 24BIT R2R + 6BIT DSD (32 steps FIR Filters)
Low Noise Power Supply
FIFO Buffer
Digital Signal Processing via FPGA
USB/I2S input supports DSD1024, USB supports PCM1536kHz, and I2S supports
PCM768kHz (audio source must be compatible with local interface)
Proprietary USB Audio Solution via STM32F446 Advanced AMR Based MCU
Licensed Thesycon USB Driver For Windows Platform
Driverless On Mac & Linux
DSD
DSD64-DoP On All Input
DSD1024 On USB & I2S Input
PCM
24bits / 44.1, 48, 88.2, 96, 176.4, 192KHz On All Input
PCM1536kHz On USB Input，PCM 768KHz On I2S Input
Sampling Mode: Non-Oversampling NOS / Oversampling OS
